Murano 15

It is a hydro-ventilated thermo-stove designed to achieve significant yields and a high water yield, thanks to the larger exchange surface.

★ ★ ★ ★

Technical data

Tipology: Thermostove
Fuel: Pellets
Coating: Metal
Introduced heat output / to firebox (min÷max): 8.06 ÷ 16.51 kW
Nominal heat output (min÷max): 7.5 ÷ 15.4 kW
Nominal heat output to space (min÷max): 1.6 ÷ 1.7 kW
Nominal heat output to water (min÷max): 5.9 ÷ 13.6 kW
Heated volume: 430 m³
Nominal performance: 93.3 %
Particulate matter: 12.2 mg/Nm³
CO emissions at 13% O²: 167 mg/Nm³
Power levels: 5
Flue gas outlet: Rear, Upper
Air ducting: No
Weight: 161 kg
Dimensions WxDxH: 62 x 61 x 113 cm
Pellet tank capacity: 33 kg
Flue gas output diameter: 80 mm

★ ★ ★ ★

This product complies with the Class 4 Stars, according to the emission and performance requirements of the Decree of 7 November 2017, n°186 (Italy).

Feature

Patented self-cleaning burner
Tank anti-backflame safety
Double ignition element
Robust structure
Hermetically sealed pellet hopper

Supplied Accessories

Electronic circulator pump
DHW probe
Water tank probe
Hydraulic safety devices kit: expansions vase, 3 bar outlet valve, automatic vent valve, system drain.
Ash drawer
"L" bar for ash cleaning
