Roma 25

Ecological pellet thermo-stove made with steel structure, top and sides in black silk-screened glass and stone facade, in 4 modern and design color versions: clean shapes and quality materials, for a pleasant view even with the flame out.
The door is composed of a double glass: black external glass, curved and elegant, and transparent ceramic glass which hermetically closes the hearth.
Thanks to their energy efficiency and low atmospheric emissions, our thermo stoves are certified with 4 or 5 stars and benefit from the greater deductions provided in Italy by the Conto Termico.

On the return circuit, a chemical-physical water treatment system must be installed, for instance a magnetic dislimer.

★ ★ ★ ★

Technical data

Tipology: Thermostove
Fuel: Pellets / Biomass
Coating: MDi
Introduced heat output / to firebox: 25.67 kW
Nominal heat output (min÷max): 8.1 ÷ 29.98 kW
Nominal heat output to space (min÷max): 0.62 ÷ 1.85 kW
Nominal heat output to water (min÷max): 7.48 ÷ 22.13 kW
Heated volume: 640 m³
Nominal performance: 93.4 %
CO emissions at 13% O²: 80 mg/Nm³
Power levels: 6
Flue gas outlet: Rear, Upper
Air ducting: No
Weight: 272 kg
Dimensions WxDxH: 63 x 67 x 131 cm
Pellet tank capacity: 32 kg
Flue gas output diameter: 80 mm

★ ★ ★ ★

This product complies with the Class 4 Stars, according to the emission and performance requirements of the Decree of 7 November 2017, n°186 (Italy).

Feature

Mechanical safety devices: 3 bar outlet valve, boiler thermostat, air pressure switch and water pressure switch.
Safety electrical safety devices: inductive sensors that constantly check the position of motors rotation; flue gas probe.

Supplied Accessories

Anti-condensation valve with thermostatic control of the system return temperature.
System pressure gauge.
Kit for DHW circuit: anti-condensation valve, electronic circulator system, DHW probe.
"L" bar for ash cleaning
Collar for top flue header
Hydraulic safety devices kit: expansions vase, 3 bar outlet valve, automatic vent valve, system drain.
Water tank probe
