Thema 12
Great performance in a small space
The goal of facilitating the installation of the domestic fireplace in narrow spaces and the search for elegance of design, are at the origin of Thema.
A refined stove where the mystery of the rounded "magic" glass merges with the sobriety of the stone, made of pure minerals melted at high temperature (MDi).
★
★
★
★
Technical data
- Tipology
- Stove
- Fuel
- Pellets / Biomass
- Coating
- MDi, Metal, Stone
- Introduced heat output / to firebox
- 12.46 kW
- Nominal heat output (min÷max)
- 5 ÷ 11.5 kW
- Heated volume
- 80 ÷ 350 m³
- Nominal performance
- 92.3 %
- CO emissions at 13% O²
- 84 mg/Nm³
- Power levels
- 6
- Flue gas outlet
- Rear, Upper
- Air ducting
- Yes
- Weight
- 152 kg
- Dimensions WxDxH
- 87 x 38 x 118 cm
- Pellet tank capacity
- 18 kg
- Flue gas output diameter
- 80 mm
★
★
★
★
This product complies with the Class 4 Stars, according to the emission and performance requirements of the Decree of 7 November 2017, n°186 (Italy).
Feature
- Two heating elements
- Hermetically sealed pellet hopper
- Ductable with dedicated fan
- Robust structure up to 4 mm thick
- Mechanical safety devices with two manual reset thermostats and a pressure switch
- Safety electrical safety devices: inductive sensors that constantly check the position of motors rotation; flue gas probe.
Supplied Accessories
- "L" bar for ash cleaning
Accessories on demand
- Wi-Fi remote control via APP
- Wall-mounted room thermostat, allows air and temperature regulation in the ducted area.
